DIEL變壓器ME100

：吳工  泉州

：1885 9564 765

：2781499592  q

Diel - Eletronics Devices總部位于意大利，公司主要有商業支持和技術支持兩個部門。公司主要生產溫度監控器、變壓器風扇和探頭。產品型號眾多，功能全面，性能卓越，在同行業中享有極高的聲譽。

Diel主要產品：

溫度監控器

MT200 LITE、AT100、MT200 LITE EN50121-5、MT300、ME100、ME100 V2

變壓器風扇

AT100、FAN400、FAN900、FAN1800、FAN3300

探頭

PT 100S、PT 100T、PT 100HV、PT 100V

Microprocessor temperature monitor system for resin, dry and oil transformers with 8 inputs for 3 wires PT100 probes

Control and showing temperature

Control of fan systems

Eight independent PT100 inputs with three wires

Four 250 Volt 10 A AC (resistive load) relays of outputs for the following functions: pre alarm state, alarm state, fault probe state, fan control with hysteresis (ME100 – ME100 V3)

Five 250 Volt 10 A AC (resistive load) relays of outputs for the following functions: pre alarm state, alarm state, fault probe state, separate fan control with hysteresis (ME100 V2)

Manual test relays to simulate or check the reliability of the contact

Advanced programming menu: is allowed able, enable and set separately each single channel

Permanent storing of programmed set of pre-alarm and alarm state, on, off fan and history values achieved

Assembly on panel by simple fixing jaws

Universal power supply (24 ÷ 240) Volt AC/DC 50/60Hz

Serial communication port RS485 full duplex,

own ASCII communication protocol (ME100)

Galvanically insulated analogical output 4-20mA (ME100 V2)

Protocol of MODBUS – RTU communication (ME 100 V3)

Protocol of MODBUS – TCP, ETHERNET communication (ME 100 E)

 DIEL變壓器ME100
